******* Product Information *******
----------------------------------
Product Name: KURO-BOX/HG(IESHIGE)
          VER: 1.00
         Date: 2004/10/19 17:18:54
----------------------------------
Firmware check:done.

>>root=/dev/hda1
Now Loading...done.
Now Booting
Memory BAT mapping: BAT2=128Mb, BAT3=0Mb, residual: 0Mb
Linux version 2.4.17_mvl21 (root@toda_dev.melcoinc.co.jp) (gcc version 2.95.3 20010315 (release/MontaVista)) #24 2004?? 10ｷ・19ﾆ・ｲﾐﾍﾋﾆ・17:17:03 JST
KURO-BOX (C) 2004 KUROUTO-SHIKOU.
On node 0 totalpages: 32768
zone(0): 32768 pages.
zone(1): 0 pages.
zone(2): 0 pages.
Kernel command line: root=/dev/hda1
OpenPIC Version 1.2 (1 CPUs and 139 IRQ sources) at 80040000
decrementer frequency = 32.618940 MHz
Calibrating delay loop... 173.67 BogoMIPS
Memory: 124760k available (1244k kernel code, 556k data, 188k init, 0k highmem)
Dentry-cache hash table entries: 16384 (order: 5, 131072 bytes)
Inode-cache hash table entries: 8192 (order: 4, 65536 bytes)
Mount-cache hash table entries: 2048 (order: 2, 16384 bytes)
Buffer-cache hash table entries: 8192 (order: 3, 32768 bytes)
Page-cache hash table entries: 32768 (order: 5, 131072 bytes)
POSIX conformance testing by UNIFIX
PCI: Probing PCI hardware
Linux NET4.0 for Linux 2.4
Based upon Swansea University Computer Society NET3.039
Initializing RT netlink socket
Starting kswapd
Disabling the Out Of Memory Killer
Journalled Block Device driver loaded
pty: 256 Unix98 ptys configured
MELCO INC. RTC driver ver 1.00
Serial driver version 5.05c (2001-07-08) with MANY_PORTS SHARE_IRQ SERIAL_PCI enabled
ttyS00 at 0x80004600 (irq = 138) is a 16550A
ttyS01 at 0x80004500 (irq = 137) is a 16550A
block: 128 slots per queue, batch=32
RAMDISK driver initialized: 16 RAM disks of 10000K size 1024 blocksize
Uniform Multi-Platform E-IDE driver Revision: 6.31
ide: Assuming 33MHz system bus speed for PIO modes; override with idebus=xx
CMD680: IDE controller on PCI bus 00 dev 60
CMD680: chipset revision 2
CMD680: 100% native mode on irq 17
    ide0: BM-DMA at 0xbffed0-0xbffed7, BIOS settings: hda:pio, hdb:pio
    ide1: BM-DMA at 0xbffed8-0xbffedf, BIOS settings: hdc:pio, hdd:pio
hda: WDC WD20EARS-00S8B1, ATA DISK drive
ide0 at 0xbffef8-0xbffeff,0xbffef6 on irq 17
hda: -387938128 sectors (2000399 MB), CHS=243201/255/63, UDMA(33)
Partition check:
 hda: hda1 hda2 hda3 hda4
FLASHDISK:Initialized [FUJITSU MBM29PL32TM]
eth0: RTL8169s/8110s Gigabit Ethernet driver supports Jambo Frame 1.8n4b <2004-3-16> at 0xc9000f00, 00:0d:0b:ad:a3:a3, IRQ 16
eth0: Auto-negotiation Enabled.
eth0: 1000Mbps Full-duplex operation.
SCSI subsystem driver Revision: 1.00
request_module[scsi_hostadapter]: Root fs not mounted
usb.c: registered new driver usbdevfs
usb.c: registered new driver hub
hcd.c: ehci-hcd @ 00:0e.2, PCI device 1033:00e0 (NEC Corporation)
hcd.c: irq 19, pci mem c9002f00
usb.c: new USB bus registered, assigned bus number 1
hcd/ehci-hcd.c: USB 2.0 support enabled, EHCI rev 1. 0
hub.c: USB hub found
hub.c: 5 ports detected
usb-ohci.c: USB OHCI at membase 0xc9004000, IRQ 19
usb-ohci.c: usb-00:0e.0, NEC Corporation USB
usb.c: new USB bus registered, assigned bus number 2
hub.c: USB hub found
hub.c: 3 ports detected
usb-ohci.c: USB OHCI at membase 0xc9006000, IRQ 19
usb-ohci.c: usb-00:0e.1, NEC Corporation USB (#2)
usb.c: new USB bus registered, assigned bus number 3
hub.c: USB hub found
hub.c: 2 ports detected
usb.c: registered new driver usblp
printer.c: v0.11: USB Printer Device Class driver
Initializing USB Mass Storage driver...
usb.c: registered new driver usb-storage
USB Mass Storage support registered.
NET4: Linux TCP/IP 1.0 for NET4.0
IP Protocols: ICMP, UDP, TCP, IGMP
IP: routing cache hash table of 1024 buckets, 8Kbytes
TCP: Hash tables configured (established 8192 bind 8192)
NET4: Unix domain sockets 1.0/SMP for Linux NET4.0.
NET4: AppleTalk 0.18a for Linux NET4.0
RAMDISK: Compressed image found at block 0
Freeing initrd memory: 2137k freed
fff70000:4f4b4f4b
EXT2-fs warning: checktime reached, running e2fsck is recommended
VFS: Mounted root (ext2 filesystem).
fff70000:4f4b4f4b
kjournald starting.  Commit interval 5 seconds
EXT3-fs: mounted filesystem with ordered data mode.
VFS: Mounted root (ext3 filesystem) readonly.
change_root: old root has d_count=2
Trying to unmount old root ... okay
Freeing unused kernel memory: 188k init
modprobe: modprobe: Can't locate module char-major-4
INIT: version 2.78 booting
Activating swap...
Adding Swap: 530136k swap-space (priority -1)
EXT3 FS 2.4-0.9.17, 10 Jan 2002 on ide0(3,1), internal journal
/dev/ttyS1 detected.
************************************************
Select the OS in 3 secs: (default is 2)
1: Linux
2: Debian

** Default **
** No.2 **
/etc/init.d/rcS: [: -f: binary operator expected
Warning: kernel-module version mloader module loaded
ismatch
        /boot/kernel=/boot/vmlinux.bin
loader.o was comcmdline=root=/dev/hda3
piled for kernel version 2.4.17_kuro-box
        while this kernel is version 2.4.17_mvl21
Warning: loading /boot/loader.o will taint the kernel: forced load


KERNELBASE=c0000000 (r6=83b7a9 r7=83b7b7) r3=0 (r4=0 r5=0)
Linux version 2.6.25.1-kuroboxHG (hiroyuki@hg-lan) (gcc version 4.1.2 20061115 (prerelease) (Debian 4.1.1-21)) #9 Sun May 4 21:29:57 JST 2008
Early serial console at MMIO 0x80004600 (options '57600n8')
console [uart0] enabled
BUFFALO Network Attached Storage Series
(C) 2002-2005 BUFFALO INC.
Zone PFN ranges:
  DMA             0 ->    32768
  Normal      32768 ->    32768
Movable zone start PFN for each node
early_node_map[1] active PFN ranges
    0:        0 ->    32768
Built 1 zonelists in Zone order, mobility grouping on.  Total pages: 32512
Kernel command line: root=/dev/hda3  console=ttyS0,57600
OpenPIC Version 1.2 (1 CPUs and 11 IRQ sources) at 80040000
PID hash table entries: 512 (order: 9, 2048 bytes)
decrementer frequency = 32.522240 MHz
Console: colour dummy device 80x25
Dentry cache hash table entries: 16384 (order: 4, 65536 bytes)
Inode-cache hash table entries: 8192 (order: 3, 32768 bytes)
Memory: 126848k available (2176k kernel code, 756k data, 140k init, 0k highmem)
Mount-cache hash table entries: 512
net_namespace: 152 bytes
NET: Registered protocol family 16
PCI: Probing PCI hardware
PCI: Cannot allocate resource region 1 of device 0000:00:00.0
SCSI subsystem initialized
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
NET: Registered protocol family 2
IP route cache hash table entries: 1024 (order: 0, 4096 bytes)
TCP established hash table entries: 4096 (order: 3, 32768 bytes)
TCP bind hash table entries: 4096 (order: 2, 16384 bytes)
TCP: Hash tables configured (established 4096 bind 4096)
TCP reno registered
io scheduler noop registered
io scheduler anticipatory registered (default)
io scheduler deadline registered
io scheduler cfq registered
I2C: rs5c372 RTC driver successfully loaded
Serial: 8250/16550 driver $Revision: 1.90 $ 4 ports, IRQ sharing disabled
serial8250.0: ttyS0 at MMIO 0x80004600 (irq = 26) is a 16550A
console handover: boot [uart0] -> real [ttyS0]
serial8250.1: ttyS1 at MMIO 0x80004500 (irq = 25) is a 16550A
brd: module loaded
loop: module loaded
r8169 Gigabit Ethernet driver 2.2LK loaded
eth0: RTL8110s at 0xc9000f00, 00:0d:0b:ad:a3:a3, XID 04000000 IRQ 16
eth0: 100Mbps Half-duplex operation.
Uniform Multi-Platform E-IDE driver
ide: Assuming 33MHz system bus speed for PIO modes; override with idebus=xx
SiI680: IDE controller (0x1095:0x0680 rev 0x02) at  PCI slot 0000:00:0c.0
siimage: IDE controller MMIO ports not available.
SiI680: BASE CLOCK == 100
SiI680: 100% native mode on irq 17
    ide0: BM-DMA at 0xbffed0-0xbffed7, BIOS settings: hda:DMA, hdb:PIO
    ide1: BM-DMA at 0xbffed8-0xbffedf, BIOS settings: hdc:PIO, hdd:PIO
hda: WDC WD20EARS-00S8B1, ATA DISK drive
hda: UDMA/100 mode selected
ide0 at 0xbffef8-0xbffeff,0xbffef6 on irq 17
hda: max request size: 64KiB
hda: 3907029168 sectors (2000398 MB), CHS=65535/255/63
hda: cache flushes supported
 hda: hda1 hda2 hda3 hda4
Driver 'sd' needs updating - please use bus_type methods
physmap platform flash device: 00400000 at ffc00000
physmap-flash.0: Found 1 x16 devices at 0x0 in 8-bit bank
 Amd/Fujitsu Extended Query Table at 0x0040
physmap-flash.0: Swapping erase regions for broken CFI table.
number of CFI chips: 1
cfi_cmdset_0002: Disabling erase-suspend-program due to code brokenness.
cmdlinepart partition parsing not available
RedBoot partition parsing not available
Using physmap partition information
Creating 5 MTD partitions on "physmap-flash.0":
0x00000000-0x00300000 : "mtd_firmimg"
0x00300000-0x00370000 : "mtd_bootcode"
0x00370000-0x00380000 : "mtd_status"
0x00380000-0x00400000 : "mtd_conf"
0x00000000-0x00400000 : "mtd_allflash"
usbmon: debugfs is not available
ehci_hcd 0000:00:0e.2: EHCI Host Controller
ehci_hcd 0000:00:0e.2: new USB bus registered, assigned bus number 1
ehci_hcd 0000:00:0e.2: irq 19, io mem 0xbfffcf00
ehci_hcd 0000:00:0e.2: USB 2.0 started, EHCI 1.00, driver 10 Dec 2004
usb usb1: configuration #1 chosen from 1 choice
hub 1-0:1.0: USB hub found
hub 1-0:1.0: 5 ports detected
ohci_hcd 0000:00:0e.0: OHCI Host Controller
ohci_hcd 0000:00:0e.0: new USB bus registered, assigned bus number 2
ohci_hcd 0000:00:0e.0: irq 19, io mem 0xbfffe000
usb usb2: configuration #1 chosen from 1 choice
hub 2-0:1.0: USB hub found
hub 2-0:1.0: 3 ports detected
ohci_hcd 0000:00:0e.1: OHCI Host Controller
ohci_hcd 0000:00:0e.1: new USB bus registered, assigned bus number 3
ohci_hcd 0000:00:0e.1: irq 19, io mem 0xbfffd000
usb usb3: configuration #1 chosen from 1 choice
hub 3-0:1.0: USB hub found
hub 3-0:1.0: 2 ports detected
Initializing USB Mass Storage driver...
usbcore: registered new interface driver usb-storage
USB Mass Storage support registered.
mice: PS/2 mouse device common for all mice
i2c /dev entries driver
TCP cubic registered
NET: Registered protocol family 1
NET: Registered protocol family 17
kjournald starting.  Commit interval 5 seconds
EXT3-fs: mounted filesystem with ordered data mode.
VFS: Mounted root (ext3 filesystem) readonly.
Freeing unused kernel memory: 140k init
INIT: version 2.86 booting
Setting parameters of disc: (none).
Setting the system clock.
Activating swap...Adding 530136k swap on /dev/hda2.  Priority:-1 extents:1 across:530136k
done.
EXT3 FS on hda3, internal journal
Setting the system clock.
Cleaning up ifupdown....
Loading kernel modules...done.
Checking file systems...fsck 1.41.3 (12-Oct-2008)
done.
Setting kernel variables (/etc/sysctl.conf)...done.
Mounting local filesystems...kjournald starting.  Commit interval 5 seconds
EXT3 FS on hda4, internal journal
EXT3-fs: mounted filesystem with ordered data mode.
done.
Activating swapfile swap...done.
Setting up networking....
Configuring network interfaces...Internet Systems Consortium DHCP Client V3.1.1
Copyright 2004-2008 Internet Systems Consortium.
All rights reserved.
For info, please visit http://www.isc.org/sw/dhcp/

r8169: eth0: link up
eth0: 1000Mbps Full-duplex operation.
Listening on LPF/eth0/00:0d:0b:ad:a3:a3
Sending on   LPF/eth0/00:0d:0b:ad:a3:a3
Sending on   Socket/fallback
DHCPDISCOVER on eth0 to 255.255.255.255 port 67 interval 7
DHCPOFFER from 192.168.1.1
DHCPREQUEST on eth0 to 255.255.255.255 port 67
DHCPACK from 192.168.1.1
bound to 192.168.1.40 -- renewal in 152279676 seconds.
if-up.d/mountnfs[eth0]: waiting for interface lo before doing NFS mounts (warning).
done.
INIT: Entering runlevel: 2
Starting enhanced syslogd: rsyslogd.
Starting OpenBSD Secure Shell server: sshd.
Starting KURO-BOX event daemon: kuroevtd.
Starting internet superserver: inetd.
Starting Samba daemons: nmbd smbd.
Starting NTP server: ntpd.
Starting periodic command scheduler: crond.
warning: `ntpd' uses 32-bit capabilities (legacy support in use)
Starting web server: apache2apache2: Could not reliably determine the server's fully qualified domain name, using 192.168.1.40 for ServerName
.
Starting mail retriever agent: fetchmail.
ttyS1 port init : AVR init string send.

Debian GNU/Linux 5.0 KURO-BOX ttyS0

KURO-BOX login:
